STL6810
STL6810系列是一款BLDC風扇控制器，具備±5%轉速變化內的先進閉環控制。內建的軟開關及先進的定時控制提高了電機效率及減少了振動。STL6810支援直接PWM輸入，不需要PWM到DC轉換的電路，從而減少外部元件數量。友好的編程介面可以調整任何風扇曲線設置。該設備提供可調的PWM輸出頻率，以支持單相全橋驅動電機繞組。 STL6810 具備軟啟動功能，並可編程增量佔空比，以抑制線圈電流的啟動尖峰，並能減少啟動噪音以及降低功耗。內置的軟開關功能可減少聲學噪音和功率損耗。該設備通過內部基準電壓提供電流限制功能。該設備支援鎖定偵測，並自動停止輸出電流。一旦外部負載放鬆，它將自動恢復至系統指定的速度。多種開漏輸出類型，如 FG、RD、停止 RD 和反向 RD，被實現為測速計，以便系統監測具有 4、6 或 8 個磁極的直流風扇的速度。
Features
- Support Hall sensor / Hall IC input
- Built-in On-line Tuning for iterative performance tuning
- 15Hz ~ 100KHz PWM input frequency range with reversible polarity
- Support soft start with programmable duty cycle
- Support brake before soft start and brake for stop
- Support 25KHz and 50KHz PWM output
- Built-in soft-switch function with programmable duration
- Support timing control for better performance
- Closed-loop fan speed control within ±5% accuracy of rotation speed
- Programmable linear curve set by [HS], [LS], and [S0]
- Programmable fan speed curve set by 6 points
- Various open-drain tachometers: FG, RD, Stop RD and Reverse RD
- Built-in programmable period for lock detection and auto recovery
- Built-in thermal protection circuit (150°C)
- Support internal current-limit setting with 7 levels
- Support current-limit setting from external pin
- Support programmable VIH level (1.6V or 1.8V)
- Support programmable UVLO threshold
- Wide product selection to support 2, 4, 6, 8 or 12 magnetic poles
- 2-wire communication channel to program parameters in OTP memory
- Parameters can be programmed twice
- Compact DFN16 package
- Green package available
- RoHS compliant and Halogen free
- Support Hall sensor / Hall IC input
